Prestage Gear Box

Prestage Gear Box introduce

The Prestage Gear Box is usually used as a pre - attached device for worm gear reducers, mainly for the preliminary adjustment and conversion of rotational speed and torque in the power transmission system.

1.Compact and Lightweight Design
It features a compact structure with a small size and light weight. This makes it easy to install and suitable for use in equipment with limited space, effectively saving the installation space of the equipment without adding excessive burden to it.

2.Precise Gear Transmission
High - precision gear processing technology is adopted, resulting in a high - precision gear meshing. The transmission is smooth, which can effectively reduce vibration and noise during the transmission process, improving the operational comfort and stability of the equipment.

3.Good Adaptability
It can adapt to a variety of different working environments and operating conditions. It can operate stably under different temperatures, humidities, and dust conditions. With a certain protection level, it can meet the usage requirements of some harsh industrial environments.

4.Diverse Installation Methods
It has multiple installation methods, such as flange - mounted and shaft - mounted. According to different equipment requirements and installation spaces, appropriate installation methods can be selected, which is convenient for connection and matching with various motors, reducers, and other equipment.

5.Reliable Sealing Performance
High - quality seals and sealing structures are used to effectively prevent lubricating oil leakage and the entry of external impurities into the gearbox. This ensures the cleanliness inside the gearbox and good lubrication conditions, extending the service life of components such as gears and bearings.

1.Improve System Efficiency
By optimizing the gear transmission ratio and transmission efficiency, it can effectively adjust the input rotational speed and torque without excessive energy consumption. Thus, it improves the working efficiency of the entire transmission system and reduces energy consumption.

2.Prolong Equipment Lifespan
The precise manufacturing process and good lubrication and sealing conditions reduce the wear of components such as gears and bearings, lowering the equipment failure rate. Consequently, it extends the service life of the equipment and reduces the equipment maintenance and replacement costs.

3.Reduce Equipment Cost
Due to its compact design and high transmission efficiency, it can, to a certain extent, reduce the overall size and power requirements of the equipment. Therefore, it decreases the manufacturing cost and operating cost of the equipment, showing good economic efficiency.

4.Enhance System Stability
It plays a buffering and regulating role in the transmission system, effectively reducing the impact and vibration of equipment such as motors and reducers during start - up and shutdown. This enhances the stability and reliability of the entire transmission system, improving the working accuracy and quality of the equipment.

5.Easy Maintenance
It has a simple structure, is easy to disassemble and install, and convenient for daily inspection, maintenance, and servicing. At the same time, its reliable sealing performance and good lubrication conditions also reduce the workload and difficulty of maintenance, lowering the maintenance cost.







Technical data:

Product Name	Prestage gear box
Model	PC63 / PC71 / PC80 / PC90
Gear Ratio	1/2.42 ~ 1/3
Motor power and poles	0.09 ~ 2.20kw(2P, 4P, 6P, 8P)
Output shaft diameter	Φ11, Φ14, Φ19, Φ24, Φ28
Code of installation form	B3, B8, B6, B7, V5, V6
Color of painting	Blue, grey
