Planetary Drive Gearbox
Advantage: small size while big torque, wide power range, wide speed range.
Product Features
1. High modular design, rich optional accessories.
2. Compact design and dimension, lightweight.
3. Wide range of ratio, high efficiency, stable running, and low noise level.
4. Realize the coaxial transmission easily.
Product Specification
|
ANG Industrial Planetary Drive Gearbox |
|
|
Type |
Helical parallel shaft type, Bevel-helical right-angle type |
|
Model |
P1 ~ P21 |
|
Input power |
1.5KW ~ 8000 KW; |
|
Input speed |
750rpm 1000rpm 1500rpm 3000rpm |
|
Reduction ratio |
1/3.5 ~ 1/4000 |
|
Output torque |
3 ~ 900kN.m |
|
Install type |
Foot / Solid shaft / Hollow shaft / Output flange… |
|
Efficiency |
Single-stage 98%, 2-stage 96%, 3-stage 94%, 4-stage 92% |
|
Precision of gear |
Accurate grinding, class 6 |
|
Accessories |
Foot base / Torque arm / Cooling fan / Cooling coil / Oil pump / Compensation tank … |
|
Options |
Easily combined with other gearboxes, such as helical, worm, bevel, or helical-bevel gearbox |
Typical Applications
Mixers Drives
Steel Plate Conveyors.
Scraper Conveyors
Roller Presses
Bucket Wheel Drives
Running Mechanism Drives
Slewing Mechanism Drives
Chain Conveyors
Rotary Kilns Drives
Pipe Rolling Mill Drives
Tube Mill Drives
Chemical agitators
Hoist and transport
Steel and metallurgy
Coal mining
Cement and construction
Paper and light industry
What Are The Main Types Of Planetary Drive Gearboxes?
The most common types of planetary gearboxes include:
1. Inline Coaxial Planetary Gearbox:
This type has a compact and efficient design that is perfect for use in applications that require high precision, low backlash, and high torque. Inline planetary gearboxes are easy to install, and maintain, and can operate at a high speed.
2. Right Angle Planetary Gearbox:
This type of gearbox is designed for applications where space is limited and where the gearbox needs to be installed at a right angle to the motor. Right-angle planetary gearboxes have high efficiency and ensure a smooth operation, even at high speeds.
What Is The Advantage Of Our Planetary Drive Gearbox?
Related Hot Selling Product
What is a Planetary Drive Gearbox?
A planetary drive gearbox is a type of gearbox that uses a planetary gear system to transmit torque and power from a motor to a driven mechanism. This type of gearbox can also be referred to as an epicyclic gearbox or a sun and planet gearbox.
The planetary gear system is made up of a sun gear, planet gears, and a ring gear. The sun gear is typically the central gear, and the planet gears revolve around it, rotating on their axes as they travel around the sun gear. The planet gears are fixed to a carrier that rotates around the sun gear. The ring gear is an outer gear that meshes with the planet gears.
One of the main advantages of a planetary drive gearbox is its high efficiency. The planetary system allows for multiple gear meshes to share the load and distribute torque evenly, reducing gear wear and increasing efficiency. Additionally, the compact size of planetary gearboxes makes them a popular choice in many applications where space is at a premium.
Planetary drive gearboxes are commonly used in a variety of industries, including aerospace, automotive, and industrial manufacturing. They can be found in applications such as gas and diesel engines, hydraulic systems, and power transmission systems. They are also used in many robotics and automation systems, where precise and efficient control is essential.
Overall, the planetary drive gearbox is an innovative and reliable transmission solution that continues to play a vital role in modern engineering and technology. Its unique design and high efficiency make it a popular choice for a wide range of applications across various industries.
FAQ
Q: Can you make the planetary drive gearbox with customization?
A: Yes, we can customize per your request, like flange, shaft, configuration, painting color, etc.
Q: Do you provide samples?
A: Yes. A sample is available for testing.
Q: How to ship to us?
A: It is available by air, by sea, or by train.
Q: How to pay the money?
A: T/T and L/C are preferred, with a different currency, including USD, EUR, RMB, etc.
