Stainless Steel Electric Motor

Product Introduction

Our stainless steel electric motor is an innovative product that combines advanced technology with outstanding quality. It is specially designed for industries with strict requirements for equipment durability, hygiene standards, and performance. Made of high - quality stainless steel, it has excellent corrosion resistance and can operate stably in various harsh environments. Whether it is the food processing, pharmaceutical, chemical, or marine industries, this electric motor can provide you with reliable power support, helping you improve production efficiency and reduce maintenance costs.

1. High - quality Stainless Steel Construction: The motor body is crafted from high - quality stainless steel, which has strong corrosion resistance. It can effectively resist the erosion of various chemicals, ensuring the long - term stable operation of the motor even in harsh environments full of corrosive substances.

2. Advanced Sealing and Protection Technology: An advanced sealing design is used to form multiple protective barriers. It can strictly block the intrusion of dust, moisture, and other contaminants, ensuring that the precision components inside the motor always operate in good condition and greatly extending the service life of the motor.

3. Flexible Speed Regulation Function: Equipped with an advanced speed control system, it can be flexibly adjusted according to different work requirements. Whether it is precise control at low - speed operation or powerful power output at high - speed operation, it can handle it easily, providing strong support for various complex production processes.

4. Efficient Heat Dissipation System: It has an efficient heat dissipation design that can quickly and effectively dissipate the heat generated during the operation of the motor. Even during long - term continuous operation, it can maintain a stable operating temperature, avoiding performance degradation and equipment damage caused by overheating.

5. Quiet and Stable Operation: Through an optimized mechanical structure and advanced manufacturing processes, the motor can maintain extremely low noise levels and minimal vibration amplitudes during operation. This not only creates a quiet and comfortable working environment for operators but also reduces the impact on surrounding equipment and the environment.

​

1. Exceptional Durability: Thanks to the high - quality stainless steel material and excellent manufacturing process, this electric motor has extremely high durability. It can withstand the tests of various harsh working conditions, reducing downtime caused by equipment damage and providing reliable guarantee for your production operations.

2. Compliance with Strict Hygiene Standards: For industries with extremely high hygiene requirements, such as the food and pharmaceutical industries, the design of this electric motor fully complies with relevant strict hygiene standards. Its smooth surface and dead - corner - free structure design facilitate cleaning and disinfection, effectively preventing bacterial growth and cross - contamination.

3. Significant Energy - Saving Effect: Advanced technology and efficient design enable the motor to significantly reduce energy consumption during operation. Compared with traditional motors, it can complete the same work tasks with lower energy consumption, saving you a large amount of operating costs.

4. Convenient Installation and Maintenance: The design of the motor fully considers the convenience of installation and maintenance. It uses standardized interfaces and structures, making the installation process simpler and faster. At the same time, its easy - to - disassemble and repair design also greatly reduces the difficulty and cost of maintenance.

5. Wide Applicability: Whether in any industrial scenario, whether for small - scale equipment or large - scale production lines, this electric motor can find a suitable application. Its versatility and adaptability make it an ideal choice for various industrial power requirements.

​





​

Power	1/4HP~30HP
Frame Size	IEC 63-90 B5 B14, NEMA 56, 140T-280
Phase	Single Phase or Three Phase
Voltage	110V115V 120V 220V 230V 240V 380V 400V 415V 440V 480V 575V 600V 660v, etc
Poles	2. 4, 6, 8 poles
Protection Class	IP55, IP56, IP65, IP67,IP69K
Enclosure Type	IC411. IC410, IC416, TENV, TEFC
Mounting Type	B14, B3, B5, B35. B34
Ambient Temperature	-15~+40°C
Altitude	≤1000M
Material	Stainless steel 304 316

Flange Options

IEC:63B5,63B14,71B5,71B14,80B5,80B14, 90B5,90B14,100B5,100B14, 112B5,112B14.132B5,160B5. 180B5 NEMA:56C,56HC,143TC,145TC,182TC,184TC,213TC,215TC,254TC,256TC,284TC,284TSC,286TC.286TSC

IEC Elektromotor Parameters at 380V 50Hz



Model	Power kW	Rated current A	Speed r/min	Eff.%	Power factor	Rated torque Nm	Tst / TN	Ist / IN	Tmax / TN	Noise dB(A)
Synchronous speed 3000 r/min
AS80M1-2	0.75	1.7	2840	80.7	0.82	2.5	2.3	7.0	2.3	62
AS80M2-2	1.1	2.4	2825	82.7	0.83	3.7	2.2	7.3	2.3	62
AS90S-2	1.5	3.2	2855	84.2	0.84	5.0	2.2	7.6	2.3	67
AS90L-2	2.2	4.6	2855	85.9	0.85	7.4	2.2	7.6	2.3	67
AS100L-2	3	6.0	2895	87.1	0.87	9.9	2.2	7.8	2.3	74
AS112M-2	4	7.8	2895	88.1	0.88	13.2	2.2	8.3	2.3	77
AS132S1-2	5.5	10.6	2920	89.2	0.88	18.0	2.0	8.3	2.3	79
AS132S2-2	7.5	14.4	2920	90.1	0.88	24.6	2.0	7.9	2.3	79
AS160M1-2	11	20.6	2960	91.2	0.89	35.5	2.0	8.1	2.3	81
AS160M2-2	15	27.9	2955	91.9	0.89	48.5	2.0	8.1	2.3	81
AS160L-2	18.5	34.2	2955	92.4	0.89	59.8	2.0	8.2	2.3	81
AS180M-2	22	40.5	2960	92.7	0.89	71.0	2.0	8.2	2.3	83

Model	Power kW	Rated current A	Speed r/min	Eff.%	Power factor		Rated torque Nm	Tst / TN	Ist / IN	Tmax / TN	Noise dB(A)
Synchronous speed 1500 r/min
AS80M1-4	0.55	1.4	1425	80.6	0.75		3.7	2.3	6.5	2.3	56
AS80M2-4	0.75	1.8	1425	82.5	0.75		5.0	2.3	6.6	2.3	56
AS90S-4	1.1	2.6	1420	84.1	0.76		7.4	2.3	6.8	2.3	59
AS90L-4	1.5	3.5	1420	85.3	0.77		10.1	2.3	7.0	2.3	59
AS100L1-4	2.2	4.8	1445	86.7	0.81		14.5	2.3	7.6	2.3	64
AS100L2-4	3	6.3	1440	87.7	0.82		19.8	2.3	7.6	2.3	64
AS112M-4	4	8.4	1460	88.6	0.82		26.1	2.2	7.8	2.3	65
AS132S-4	5.5	11.2	1460	89.6	0.83		36.0.	2.0	7.9	2.3	71
AS132M-4	7.5	15.0	1460	90.4	0.84		49.0	2.0	7.5	2.3	71
AS160M-4	11	21.5	1470	91.4	0.85		71.7	2.2	7.7	2.3	73
AS160L-4	15	28.8	1470	92.1	0.86		97.8	2.2	7.8	2.3	73
AS180M-4	18.5	35.3	1475	92.6	0.86		120	2.0	7.8	2.3	76
AS180L-4	22	41.8	1475	93.0	0.86		142	2.0	7.8	2.3	76
Synchronous speed  1000 r/min
AS80M1-6	0.37	1.1	910	73.5	0.70		3.9	1.9	5.5	2.0	54
AS80M2-6	0.55	1.5	905	77.2	0.71		5.8	1.9	5.8	2.1	54
AS90S-6	0.75	2.0	940	78.9	0.71		7.7	2.0	6.0	2.1	57
AS90L-6	1.1	2.8	935	81.0	0.73		11.3	2.0	6.0	2.1	57
AS100L-6	1.5	3.8	955	82.5	0.73		15.0	2.0	6.5	2.1	61
AS112M-6	2.2	5.4	960	84.3	0.74		21.7	2.0	6.6	2.1	65
AS132S-6	3	7.2	975	85.6	0.74		29.4	1.9	6.8	2.1	69
AS132M1-6	4	9.5	975	86.8	0.74		39.2	1.9	6.8	2.1	69
AS132M2-6	5.5	12.7	970	88.0	0.75		54.1	2.0	7.0	2.1	69
AS160M-6	7.5	16.2	970	89.1	0.79		73.5	2.0	7.0	2.1	70
AS160L-6	11	23.1	970	90.3	0.80		108	2.0	7.2	2.1	70
AS180L-6	15	30.9	975	91.2	0.81		147	2.0	7.3	2.1	73



​
