SS Reducer

Favorable price, fast delivery, timely service-- ANG is your reliable supplier of ss reducer which is free from oil leakage, low noise, low temperature rise, long service life, etc.

Send Inquiry

Product Introduction

SS Reducer Introduction

Robust and flexible

The modular design of the ss reducer: allow for a variable stainless steel motor for direct mounting, IEC, and NEMA adapters. Output and installation will satisfy different customer requirements, such as solid shaft, hollow shaft, flange, base plate, and so on.

Regardless of whether they are used for materials handling, intralogistics, or hygienic applications, their hygienic properties, long operating life, and maintenance friendliness make these high-quality stainless geared motors the perfect solution for any application.

Always a clean solution

SS reducer from ANG Drive is characterized by their special housing design and the use of high-quality inox stainless steel, recesses that can collect dirt and liquid have been eliminated as much as possible. Its surface is easy to clean and highly resistant against acids and alkalis; widely applied in salt spray, dusty, high temperature, and extremely wet environments to prevent any form of corrosion.

SS Reducer and Motor

ANG provides a wide range of ss reducer and ss motor for the food and beverage industry, including:

(1) Stainless steel electric motor: IEC metric engine, imperial Nema inch engine.

(2) Stainless steel gearbox motor: Inline helical geared motor, right angle worm reducer motor, angular bevel 90 degree gear reduction motor.

(3) Stainless steel worm reducer: IEC gearbox and inch gearbox, NMRV smooth surface reducer, NMRV with heat dissipation ribs type, VF round reducers.

SS Reducer Configurations

Typical Models	Helical Inline Reducer: R37, R47, R57, R67 Helical Bevel Right Angle Gearbox: K37, K47, K57, K67 Worm Gear Reductor: NMRV030, NMRV040, NMRV050, NMRV063, NMRV075
Motor Power	0.09KW 0.12HP, 0.12KW 0.18HP, 0.18KW 0.25HP, 0.25KW 0.33HP, 0.37 KW 0.5HP, 0.55KW 0.75HP, 0.75KW 1HP, 1.5KW 2HP, 2.2KW 3HP, 3.7 KW 5HP, 4 KW 5HP, 5.5 KW 7.5HP, 7.5KW 10HP, 11KW 15HP, 15KW 20HP, 18.5KW 25HP, 22KW 30HP
Input Speed	750rpm 900rpm 1000rpm 1200rpm 1500rpm 1800rpm 3000rpm 3600rpm
Reduction Ratio	1/5 1/7.5 1/10 1/15 1/20 1/25 1/30 1/40 1/50 1/60 1/80 1/100, etc.
Input Motor	AC IEC or NEMA (1 phase or 3 phase), DC
Output Type	Hollow shaft, solid shaft, flange
Housing Material	304 or 316 food-grade material
Dimension Standard	Metric size / Imperial size
Lubrication oil	Food grade oil
Accessories	Input flanges, Output flanges, Solid output shaft, Torque arm, etc.
Input flange options	56B5, 63B5, 63B14, 71B5, 71B14, 80B5, 80B14, 90B5, 90B14, 100B5, 100B14, 112B5, 112B14, 132B5
Applications	Food Industry Dairies and Milk-Processing Companies Pharmaceutical Industry Lab Supplications Beverage Production and Bottling Water Supply Cosmetics Industry Meat Poultry Processing Industry

SS Reducer and Electric Motor Pictures

SS Reducer Worm

SS Reducer Bevel

SS Reducer Helical

SS Motor TEFC

SS Motor TENV

SS Motor B5

SS Reducer Worm Type Parameters

Model	Ratio	Center Distance	Power	Input Dia.	Output Dia.	Output Torque
NMRV030	7.5~100	30mm	0.06KW~0.25KW	Φ11	Φ14	45N.m
NMRV040	7.5~100	40mm	0.09KW~0.55KW	Φ9(Φ11, Φ14)	Φ18(Φ19)	84N.m
NMRV050	7.5~100	50mm	0.12KW~1.5KW	Φ11(Φ14, Φ19)	Φ25(Φ24)	160N.m
NMRV063	7.5~100	63mm	0.18KW~2.2KW	Φ14(Φ19, Φ24)	Φ25(Φ28)	230N.m
NMRV075	7.5~100	75mm	0.25KW~4.0KW	Φ14(Φ19, Φ24, Φ28)	Φ28(Φ35)	410N.m
