Worm Shaft Gearbox
Worm Shaft Gearbox Features
1. Cover and Wheel core are made of high-quality cast iron
2. Shafts are made of wrought iron
3. The worm gear department after high-frequency processing, increases hardness.
4. Input shaft after modulation process, increase mechanical skills
Specification of Worm Shaft Gearbox
Type: | Gearbox WP Series |
Model: | 40-250 |
Ratio: | 10,15,20,25,30,40,50,60 |
Color: | Blue/Green Or On Customer Request |
Material: | Housing: die-cast cast iron |
Worm Gear-Copper-9-4# | |
Worm-20CrMn Ti with carburizing and quenching, the surface hardness is 56-62HRC | |
Shaft-chromium steel-45# | |
Packing: | Carton and Wooden Case |
Bearing: | HH / XZX Bearing |
Seal: | KSK |
Warranty: | 12Months |
Input Power: | 0.12kw~15kw |
Usages: | Industrial Machine: Food Stuff, Ceramics, Chemical, Packing, Dyeing, Woodworking, Glass. |
IEC Flange: | B5 |
Lubricant: | Synthetic&Mineral |
Typical Applications of Worm Shaft Gearbox
Wastewater treatment machines | Thickeners, filter presses, flocculation apparatus, aerators, raking equipment, combined longitudinal and rotary rakes,pre-thickeners, screw pumps, water turbines, centrifugal pumps | Dredgers | Bucket conveyors, dumping devices, bucket wheel excavators, bucket wheel excavators, cutter heads |
Chemical industry | Plate bending machines, extruders, dough mills, rubbers calenders, cooling drums, mixers for uniform media, agitators, toasters, centrifuges equipment | Metalworking machines | plate tilters, ingot pushers, winding machines, cooling bed transfer frames, roller straighteners, table continuous intermittent, roller tables reversing tube mills, shears continuous, casting drivers, reversing blooming mills |
Metalworking mills | Reversing slabbing mills. reversing wire mills, reversing sheet mills, reversing plate mills, roll adjustment drives | Conveyors | Bucket conveyors, hauling winches, hoists, belt conveyors, good lifts, passenger lifts, apron conveyors, escalators, rail travelling gears |
Frequency converters | Reciprocating compressors | ||
Cranes | Slewing gears, luffing gears, travelling gears, hoisting gear device, derricks jib cranes | Cooling towers | Cooling tower fans, blowers axial and radial |
Cane sugar production | Cane knives, cane mills | Beet sugar production | Beet cassettes macerators, extraction plants, mechanical refrigerators, juice boilers, sugar beet washing machines, sugar beet cutter |
Paper machines | Pulper drives | Cableways | Material ropeways, continuous ropeway |
Cement industry | Concrete mixer, breaker, rotary kilns, tube mills, separators, roll crushers | ||
Structure of Worm Shaft Gearbox
Why Choose Our Worm Shaft Gearbox?
Other Gearbox and Electric Motor
FAQ
Q: What should I provide when I choose gearbox/speed reducer?
The best way is to provide the motor drawing with parameters. Our engineer will check and recommend the most suitable gearbox model for your reference.
Or you can also provide the below specification as well:
1) Type, model, and torque.
2) Ratio or output speed
3) Working condition and connection method
4) Quality and installed machine name
