4IK25GN
Featuring a unique lubrication system, our 4IK25GN Micro gear motor reduces friction by 35%, enhancing overall efficiency. The motor's speed stability is outstanding, with a fluctuation rate less than 5% under varying loads. It incorporates a high-strength alloy gear. Additionally, its sealed design provides excellent protection against dust and moisture, guaranteeing reliable performance in harsh environments.
Long Service Life: Has a service life of over 5000 hours, reducing replacement frequency.
Precise Control: Allows for accurate positioning with an error margin within ±0.5 mm, ideal for precision instruments.
Cost-effective: Saves about 20% of the cost compared to competitors while providing equal or better performance.
|
Model |
4IK25GN |
|
Size |
80mm*80mm |
|
Power |
25w |
|
Voltage |
1-phase:220v 3-phase: 380v/220v |
|
Rated Torque |
154~ 185mNm (without reducer) |
|
Capacitor |
1.5uF ~ 8uF |
|
Motor shaft diameter |
10mm |
|
Motor weight |
1.5kg |
|
Reducer Ratio |
1/3 ~ 1/300 |
|
Reducer torque |
0.45~ 7.84Nm |
|
Reducer shaft dia. |
10mm |
|
Total weight |
2.1kg/2.2kg/2.4kg/2.5kg |
|
Total length |
96mm/144mm |
|
Why choose us? |
● Free from oil leakage ● Low noise ● Low-temperature rise ● Favorable price ● Long warranty |
