Inline Micro Gear Motor
1. Compact structure and simple assembly;
2. Wide speed ranges and high torque;
3. Low noise, good sealing performance, high efficiency;
4. Stable and safe, long lifetime, universal;
5. Multi-structure, various assembling methods
The 100% power phase adaptability means it can be used globally without power concerns. In food packaging lines, it boosts production speed by 20% with its consistent power. The energy savings and durability lead to a lower total cost of ownership, providing great value for businesses.
|
Name |
Inline Micro Gear Motor |
|
Motor size |
60mm*60mm |
|
Motor power |
6w |
|
Motor speed |
1200rpm at 50Hz, 1450rpm at 60Hz |
|
Motor current |
0.13 ~ 0.25A |
|
Motor torque |
41 ~ 46mNm |
|
Capacitor |
0.8uF ~ 3uF |
|
Motor shaft diameter |
6mm |
|
Motor weight |
0.75kg |
|
Gear Ratio |
1/3 ~ 1/200 |
|
Gearbox torque |
0.12 ~ 2.5Nm |
|
Gearbox shaft dia. |
8mm |
|
Total weight |
1.15kg |
|
Total length |
115mm |
