132 Kw 176 HP Gear Motor
In the manufacturing process, we adhere to strict quality control standards, and it has been widely applied in fields such as conveyor systems, packaging machinery, and material handling equipment.
Powerful Torque Generation: Capable of producing a torque of up to 62800 Nm, it provides the necessary force for heavy machinery. In the construction industry, it can power concrete mixers, cranes, and hoists, ensuring projects progress smoothly.
Resilient Cast Iron Body: The cast iron body is built to last, withstanding vibrations and shocks. Real-world applications have shown that it can maintain stable operation even in earthquake-prone areas, protecting the integrity of the equipment.
Multi-Modal Mounting: It supports different mounting styles, such as bracket mounting and direct coupling to shafts. This versatility allows for seamless integration into existing systems. In a renewable energy power plant, it can be mounted to drive turbines and generators with precision.
- Minimized mounting space
- Wide output speed selection range
- Reduced standard backlash
- High dynamic and energy saving solution
- Wide output speed selection range
|
ANG Helical Gear Motor |
|
|
Type |
K167 ~ 187 |
|
Input power |
132kw/176 HP |
|
Input speed |
750rpm ~ 3000rpm |
|
Reduction ratio |
1/12.65 ~ 1/73.96 |
|
Input motor |
AC (1 phase or 3 phase)/ DC/ BLDC motor |
|
Installation Mode |
Foot/ Flange mounted |
|
Output Torque |
10700 ~ 62800Nm |
|
Stage |
2, 3 |
|
Input form |
Direct Motor, IEC Standard Motor, Solid input Shaft |
|
Output form |
Solid shaft |
