R Series Gear Reducer
Favorable price, fast delivery, timely service-- ANG is your reliable supplier of gearbox which is free from oil leakage, low noise, low temperature rise, long service life, etc.
Send Inquiry
Product Introduction
Technical Parameter
| Housing material | HT200 high-strength cast iron(R37, R47, R57, R67, R77, R87) |
| Housing material | HT250 High strength cast iron(R97, R 107, R137, R147, R167) |
| Gear material | 20CrMnTi |
| Gear Surface&hardness | HRC58°-62° |
| Gear core hardness | HRC33°-78° |
| Input/Output shaft material | 40Cr |
| Gear Machining precision | Accurate grinding 6-5 grade |
| Heat treatment | Carburizing, Quenching etc |
| Efficiency | Up to 92% |
| Noise(Max) | 60-67dB |
| Installation type | Foot mounted, flange mounted |
| Output type | Solid shaft |
| Bearing brand | NSK, SKF, HRB, ZWZ etc |
| Oil seal brand | NAK, KSK etc |
| Lubricant | VG220 |
| Motor | IP55, F class |
| Motor shaft | 40Cr, Carburizing, Quenching etc |
| Warranty | 12months |
| Color | Blue, Grey |
Application:
Ceramic Industry
Glass Industry
Food Industry
Metallurgy Industry
Beer& Drink Industry
Printing and dyeing Industry
Textile Industry
Warehouse Logoistics Industry
Wood working Machinery
environmental protection equipment Industry
Leather Industry
Pharmacy Industry
