Lift Electric Motor

Favorable price, fast delivery, timely service-- ANG is your reliable supplier of transmission solution, which is high efficiency, low noise, low temperature rise, long service life, etc.

Send Inquiry

Product Introduction

General specification of lift electric motor:

Power	0.06 ~ 315kw
Frame Size	56 ~ 355
Phase	Single or Three
Efficiency Class	IE1 ~ IE4
Poles	2, 4, 6, 8 poles
Protection Class	IP44, IP54, IP55, IP56, IP65, IP67
Insulation Class	B, F, H
Mounting Type	B14, B3, B5, B35, B34
Ambient Temperature	-15 ~ +40 °C
Altitude	≤1000M
Material	Aluminum / Cast Iron / Stainless steel

Some models of lift electric motor:

SYNCHRONOUS OUTPUT SPEED=3000RPM FREQUENCY=50HZ VOLTAGE=380V

MODEL	POWER (KW)	SPEED (RPM)	CURRENT (A)	EFFICIENCY	POWER FACTOR	IST/IN	TST/TN	TMAX/TN	Static brake torque is not less than N.m	Excitation voltage UF(V)	Moment of inertia GB²	NOISE dB(A)
YEJ-132S1-2	5.5kw	2900rpm	11.1	87	0.89	7	2.2	2.2	73.6	170	0.06434	0.4
YEJ-132S2-2	7.5kw	2900rpm	15	88.1	0.89	7	2.2	2.2	73.6	170	0.0724	0.4
YEJ-160M1-2	11kw	2930rpm	21.3	89.4	0.89	7	2.2	2.2	147.2	170	0.22853	0.5
YEJ-160M2-2	15kw	2930rpm	28.7	90.3	0.89	7	2.2	2.2	147.2	170	0.26623	0.5
YEJ-160L-2	18.5kw	2930rpm	34.7	90.9	0.89	7	2.2	2.2	215.8	170	0.346	0.5
YEJ--180M-2	22kw	2940rpm	41.2	91.3	0.89	7	2.2	2.2	294.3	170	0.37637	0.6
YEJ-200-L1-2	30kw	2950rpm	55.3	92	0.89	7	2.2	2.2	294.3	170	0.739	0.7
YEJ-200L2-2	37kw	2950rpm	67.9	92.5	0.89	7	2.2	2.2	441.5	170	0.8181	0.7
YEJ-225M-2	45kw	2970rpm	82.1	92.9	0.89	7	2.2	2.2	7.36	170	1.269	0.8
