Feeding Gearbox
feeding gear box
feeding gear unit
feeding reductor
feeding reducer

Feeding Gearbox

The feeding gearbox has been specifically designed for feeding systems in poultry farms. All gearboxes have been made up with diecast aluminum housing and single stage helical gears. A wide selection of input/output flanges and shafts is available in order to satisfy each customers’ specific demand.

Send Inquiry

Product Introduction

Poultry automatic feeding system?

farm feeding system

1. Transport system – Farm feeding gearbox

Specification sheet:

Product name	Feeding gearbox
Model number	PU01 PX01
Motor phase	AC motors, 1 phase or 3 phase
Rated power	0.25 kw ~ 1.5 kw
Input speed	1410rpm at 50Hz, 1660rpm at 60Hz
Options of input flanges	63B5, 71B14, 71B5, 80B14, 80B5

Typical ratio	1:3.93, 1:4.75, 1:5.7
Output flange types	Square flange or round flange
Output shaft types	Single keyway on shaft, hole on shaft
Application machine	Mainly used for poultry farm feeding system
