Conveyor Electric Motor
General specification of conveyor electric motor:
Power | 0.06 ~ 315kw |
Frame Size | 56 ~ 355 |
Phase | Single or Three |
Efficiency Class | IE1 ~ IE4 |
Poles | 2, 4, 6, 8 poles |
Protection Class | IP44, IP54, IP55, IP56, IP65, IP67 |
Insulation Class | B, F, H |
Mounting Type | B14, B3, B5, B35, B34 |
Ambient Temperature | -15 ~ +40 °C |
Altitude | ≤1000M |
Material | Aluminum / Cast Iron / Stainless steel |
Some models of conveyor electric motor:
Product Model | Rated Output (kw) | Speed (at full load) (r/min)
| Product Model | Rated Output (kw) | Speed (at full load) (r/min) |
YEJ180M-2 | 22 | 2940 | YEJ132M2-6 | 5.5 | 960 |
YEJ200L1-2 | 30 | 2950 | YEJ160M-6 | 7.5 | 970 |
YEJ200L2-2 | 37 | 2950 | YEJ160L-6 | 11 | 970 |
YEJ225M-2 | 45 | 2970 | YEJ180L-6 | 15 | 970 |
YEJ801-4 | 0.55 | 1390 | YEJ200L1-6 | 18.5 | 970 |
YEJ802-4 | 0.75 | 1390 | YEJ200L2-6 | 22 | 970 |
YEJ80S-4 | 1.1 | 1400 | YEJ225M-6 | 30 | 980 |
YEJ90L-4 | 1.5 | 1400 | YEJ132S-8 | 2.2 | 710 |
YEJ100L1-4 | 2.2 | 1420 | YEJ160M1-8 | 4.0 | 720 |
YEJ100L2-4 | 3.0 | 1420 | YEJ160M2-8 | 5.5 | 720 |
YEJ112M-4 | 4.0 | 1440 | YEJ160L-8 | 7.5 | 720 |
YEJ132S-4 | 5.5 | 1440 | YEJ180L-8 | 11 | 730 |
YEJ132M-4 | 7.5 | 1440 | YEJ225S-8 | 18.5 | 730 |
YEJ160M-4 | 11 | 1460 | YEJ225M-8 | 22 | 730 |
FAQ
Q: Do you provide technical support?
A: Yes. Our company has a design and development team, we can provide technical support if you need it.
Q: How to ship to us?
A: It is available by air, or by sea, or by train.
Q: How to pay the money?
A: T/T and L/C are preferred, with different currencies, including USD, EUR, RMB, etc.
