Worm Reducer

Heavy-duty WP Series Reductors: Delivering high-torque precision and superior durability for the most demanding industrial environments.

Send Inquiry

Product Introduction

Technical Parameters

Type: Worm Reductor

Model: WPO Series

Input Motor: AC (1-Phase / 3-Phase) or DC Motor

Output Torque: 6 - 6050 Nm (High Torque Capacity)

Step: Single-step transmission

Input Configuration: Solid Input Shaft

Housing Material: Premium Die-cast Iron

Notices Of Usage

1. Lubrication & Setup

• Fill with the correct category/brand of lubricant before use.

• Secure the vent plug and uncork the small cone plug to ensure proper pressure relief.

• Crucial: Change the oil after the first 100 hours of operation, then follow the manual's maintenance schedule.

2. Abnormal Operation

• If unusual conditions occur, stop the machine immediately for inspection.

• Temperature Limit: The maximum allowable oil temperature is 95°C. If the temperature stabilizes below this limit, the reducer can continue operation.

Applications For Worm Reducer

1. Safety-Critical Hoisting & Lifting

Due to high friction between the worm and wheel, these gears are naturally non-reversible. This self-locking feature is ideal for hoisting operations, heavy gates, elevators, and escalators, where reversing direction would be dangerous or damaging.

2. Industrial Manufacturing & Mining

The compact and robust design makes it a reliable choice for heavy-duty environments, including:

• Conveyor Systems: For smooth and consistent material handling.

• Presses & Metalworking: Handling high-pressure tasks with precision.

• Mining Applications: Built to withstand rugged operational demands.

3. Precision & Specialty Equipment

Worm gears provide the fine adjustment needed for delicate tasks, such as:

• Small Electric Motors: Compact power transmission.

• Rudders: Marine steering precision.

• Musical Instruments: Fine-tuning strings with accuracy.

worm gearbox advantages
