200w Gear Motor

Motor Size

100mm*100mm

Motor Power

200w

Motor Speed

1350rpm at 50Hz, 1550rpm at 60Hz

Motor Torque

1232~ 1450mNm

Capacitor

8uF ~ 36uF

Motor shaft diameter

15mm

Motor weight

5kg

Gearbox Ratio

1:3 ~ 1/250

Gearbox torque

3.17~ 42.2Nm

Gearbox shaft dia.

solid shaft: 20mm, hollow shaft: 22mm

Total weight

8.7kg/8.8kg/8.9kg/9.4kg/9.5kg

Total length

340mm/388.5mm

Why choose us?

● Free from oil leakage

● Low noise

● Low-temperature rise

● High-temperature resistant copper coil

● Hollow design, built-in fan radiator
