WP Gearbox Reducer
WP worm gearbox
WPA gear box
WPA gearbox
WPA reducer

WP Gearbox Reducer

Favorable price, fast delivery, timely service-- ANG is your reliable supplier of rectangular gear motor which is free from oil leakage, low noise, low temperature rise, long service life, etc.

Send Inquiry

Product Introduction

WP Worm Reducer Specification:

ANG WP Worm Reducer
Model	WPA WPS WPDA WPDS WPO WPX…
Size	40-250(single stage)
Input power	0.12kw ~ 33kw
Input speed	750rpm ~ 2000rpm
Reduction ratio	1/10 ~ 1/60(single stage)
Input motor	AC (1 phase or 3 phase) / DC motor
Output torque	6-6050Nm
Install type	Foot / Solid shaft / Hollow shaft…
Material of housing	Die-cast iron
Application	Food Stuff, Ceramics, Chemical, Packing, Dyeing, Woodworking, Glass, etc.

Features:

1. Compact structure and simple assembly;
2. Wide speed ranges and high torque;
3. Low noise, good sealing performance, high efficiency;
4. Stable and safe, long lifetime, universal;

Why choose us?

	Advantages ● Free from oil leakage ● Higher efficiency ● Low noise ● More reasonable and competitive price ● Excellent quality
Gear ● Precise processing ● Heat treatment to increase strength ● Able to work with heavy load ● Involute tooth profile ● Archimedes tooth profile
	Inspection ● 100% running test ● Oil leakage check ● Noise check ● Vibration test
Housing ● High strength material ● Trinity processing of each side ● Concentricity is guaranteed
