125HP Electric Motor

125HP Electric Motor General specification:

Efficiency Class:IE2
Frame Size: 280/315
Poles: 2, 4, 6poles
Rated Power: 125HP
Rated Voltage: 220/380V,380/660V,230/400V,400V/690V
Frequency: 50HZ,60HZ
Protection Class: IP44,IP54,IP55, IP56
Insulation Class: B, F, H
Mounting Type:B3,B5,B35multi and pad mounting
Ambient Temperature: -20~+40 °C
Altitude: ≤1000M

125HP Electric Motor Produce:

1. Silicon steel DR510, 800, 600, 360 standard use stamping of lamination stator and rotor die-casting

2. 100% copper winding and inserting stator (manual and semi-automatically)

3. Stator Vacuum impregnation and drying

4. CNC machining motor shaft, frame, end shields, etc

5. Professional workman inspecting spare parts every processing

6. Electric motor assembly product line

7. Electric motor will 100% test before painting.

8. Electric motor spray-paint on motor painting product line

9. Electric motor will 100% check again before packing.

An electric motor from material to finish motor, must pass 15 time check, and 100% testing, output power, voltage, electric current, non-load, 50% load, 75% load, 100% load and check the nameplate, packing. Finally shipping to our customer.

FAQ

Q: What can I do if I don't know which one I need?

A: Don't worry, just tell us some information, and we will help you.

Q: What information should I offer in my inquiry?

A:

1. Type of the motor, 1 phase or 3 phase.

2. Parameters, like power, speed.

3. Mounting type, like B5 B3 B14 B34 B35.

4. Purchase quantity.

5. Other special requirements.
