Favorable price, fast delivery, timely service-- ANG is your reliable supplier of 4 Kw Gear Motor which is free from oil leakage, low noise, high quality, long service life, etc.

Send Inquiry

Product Introduction

4 Kw Gear Motor

4 Kw Gear Motor General specification:

ANG Helical Gear Motor
Type	R47 , R57 , R67 , R77 ,R87 , R97 , R107 , R137 , R147，R167 , R177 , R187
Input power	4 kw
Input speed	750rpm ~ 3000rpm
Reduction ratio	1/1.3 ~ 1/861
Input motor	AC (1 phase or 3 phase)/ DC/ BLDC motor
Installation Mode	Foot/ Flange mounted
Output Torque	35 ~ 21500Nm
Stage	2, 3
Input form	Direct Motor, IEC Standard Motor, Solid input Shaft
Output form	Solid shaft

4 Kw Gear Motor :

Features of products
1. Highly Standard Modular Designed: The products are easily connected with and driven by different types of motors and various input power. The same type geared motor can be adapted to optioned powers of motors. It is therefore easy to realize different solution for varied requirements.
2. Ratio: Featured many closely divided ratios and wide range of them. Very big final ratios can be obtained through combined unites to reach extremely low output speeds.
3. Mounting Arrangement: No strict limitation to the mounting arrangement.
4. High Strength, Compact Dimension: Housings are made of high strength cast iron. Gears and shaft gears are finished with gas carburizing process and precise grounding to sequentially get high loading capacity of per certain volume.
5. Long Service Life: Under the condition of accurately selecting type size and the normal maintenance and use, main components (expect those easily-disabled parts) can last as long as up to more than 25,000 hours. Easily-disabled parts include lubricating oil, oil seals, and bearings.
6. Low Noise: All key components are finished by precisely machining, accurate assembly, and finally tested, and therefore, fairly low noise is reached.
7. High Efficiency: The efficiency of gear unit can reach 95%.
8. Large radial loading ability.
9. Axial load ability of up to 5% of radial load.
The advantages:
(1) With excellent quality and Reasonable price
(2) Promise to delivery on time
(3) Safe, reliable, economical and durable
(4) Stable transmission, quiet operation
(5) High heat-radiating efficiency, high carrying ability
(6) Every product must be tested before sending
